Linksys LGS116P 16-Port Gigabit PoE+ Switch – 8 PoE+ Ports, 80W Budget & QoS
Linksys LGS116P Business 16-Port Gigabit 8x PoE+
The Linksys LGS116P Business 16-Port Gigabit PoE+ Switch is a reliable unmanaged network switch designed for small businesses, surveillance systems, and office environments. Featuring 16 Gigabit Ethernet ports with 8 PoE+ ports, it delivers both data and power over a single Ethernet cable for IP cameras, VoIP phones, wireless access points, and other PoE-enabled devices. With QoS traffic prioritisation, plug-and-play deployment, and an 80W PoE budget, the LGS116P provides stable, high-speed network connectivity while simplifying device installation and expansion.
Specifications
Ports: 16× Gigabit RJ45 (8× PoE+, 8× Gigabit Ethernet)
PoE Standard: IEEE 802.3af/at
PoE Budget: 80W Total
Max PoE per Port: 30W
Switching Capacity: 32 Gbps
Forwarding Rate: 23.8 Mpps
MAC Address Table: 8000 Entries
Buffer Memory: Not Specified
VLAN Support: No
QoS: Yes (802.1p & DSCP)
IGMP Snooping: No
Link Aggregation: No
Port Mirroring: No
Flow Control: Yes
Auto MDI/MDI-X: Yes
Auto-Negotiation: Yes
Jumbo Frame: Supported
Security: IEEE 802.3x Flow Control
Dimensions: 280 × 120 × 25 mm
Case: Metal Desktop Chassis
Cooling: Fanless
Mounting: Desktop / Wall Mount
Power Input: 54V DC
Power Consumption: Max 13.41W (excluding PoE load)
Operating Temperature: 0°C to 50°C
Operating Humidity: 10% to 90% Non-Condensing
Warranty: 5-Year Manufacturer Warranty
Key Features:
8 PoE+ ports for powering IP cameras, wireless access points, and VoIP phones
80W total PoE power budget
16 Gigabit Ethernet auto-sensing ports
Quality of Service (QoS) traffic prioritisation
Plug-and-play unmanaged operation
Auto MDI/MDI-X and Auto-Negotiation support
Energy Efficient Ethernet (IEEE 802.3az)
Metal desktop chassis with wall-mount capability
Ideal for small business, surveillance, and office networks
Perfect For
CCTV/IP Camera Networks
Small Business Offices
Retail Shops
Wireless Access Point Deployment
VoIP Telephone Systems
Home Labs
Shared Workspaces
