Gigabyte B850 EAGLE ICE AM5 ATX Motherboard – DDR5, PCIe 5.0, Wi‑Fi, 3× M.2
GIGABYTE AM5 B850 EAGLE ICE ATX Motherboard
Build a powerful and modern AM5 system with the GIGABYTE B850 EAGLE ICE, a next‑generation ATX motherboard designed for gaming, productivity, and high‑performance Ryzen builds. Powered by the AMD B850 chipset, it supports Ryzen 7000 / 8000 / 9000 Series processors and delivers ultra‑fast DDR5 performance with strong overclocking capability. With PCIe 5.0 GPU support, Gen5 + Gen4 M.2 slots, 2.5GbE LAN, Wi‑Fi 6E / Wi‑Fi 7 options, USB‑C connectivity, and enhanced thermal design, this board provides next‑level speed, stability, and reliability. GIGABYTE features such as robust VRM cooling, EZ‑Latch, Smart Fan 6, and Q‑Flash Plus ensure easy installation, excellent cooling, and long‑term durability — all wrapped in a clean ICE‑white ATX design ideal for modern builds.
Specifications
Type: ATX Motherboard
Brand: GIGABYTE
Model: B850 EAGLE ICE
Chipset: AMD B850
CPU Socket: AM5
Supported CPUs: AMD Ryzen 7000 / 8000 / 9000 Series
RAM Technology: DDR5 (Dual Channel)
RAM Slots: 4 × 288‑pin
RAM Speed Support: High‑frequency DDR5 OC (varies by CPU and DIMM)
Max Memory: 192GB
PCIe Slots: 1 × PCIe 5.0 x16, additional PCIe 4.0/3.0 slots
M.2 Slots: 1 × PCIe 5.0 x4, 2 × PCIe 4.0 x4
SATA Ports: 4 × SATA 6Gb/s
RAID Support: RAID 0/1/10
LAN: 1GbE or 2.5GbE (depending on SKU)
Wireless: Wi‑Fi 6E or Wi‑Fi 7 (depending on model)
Bluetooth: 5.x
Audio Codec: Realtek High Definition Audio
Channels: 7.1‑Channel High Definition Audio
Video Outputs: 1 × HDMI, 1 × DisplayPort (Requires Ryzen CPU with integrated graphics)
Special Features:
Robust VRM cooling
EZ‑Latch PCIe & M.2
Smart Fan 6
Q‑Flash Plus
USB‑C front panel support
USB‑C rear I/O (model dependent)
USB Connectivity Rear I/O:
USB 2.0
USB 3.2 Gen1Type‑A
USB 3.2Gen2 Type‑A
USB 3.2 Gen2 Type‑C
HDMI,
DisplayPort
LAN port
Wi‑Fi antenna connectors
Audio jacks
Internal Headers:
USB 2.0 headers
USB 3.2 Gen1 header
USB 3.2 Gen2x2 Type‑C header
RGB & ARGB headers TPM header COM header Front panel connectors Multiple fan headers
Power Connectors: 24‑pin ATX 8‑pin CPU power
Form Factor: ATX (305 × 244 mm)
Package Contents:
Motherboard SATA cable
Manual Support materials
M.2 screws
Wi‑Fi antennas (Wi‑Fi models)
Most Suitable For
High‑performance AM5 gaming PCs
Ryzen 7000 / 8000 / 9000 Series builds
PCIe 5.0 GPU + Gen5 NVMe setups
Wi‑Fi 6E / Wi‑Fi 7 + 2.5Gb LAN connectivity
White‑themed ICE builds
ATX mid‑tower and full‑tower systems
