Asus ROG Strix X870E-E Gaming Wifi Motherboard, DDR5, AMD AM5, PCIe5, X870

AMD AM5 X870E-E Gaming Motherboard, ATX, WiFi 7

The Asus ROG Strix X870E-E Gaming WiFi motherboard is engineered for high-performance gaming, AI development, and rendering tasks. Featuring the latest AMD AM5 socket and DDR5 memory support, it delivers exceptional speed and responsiveness. With PCIe 5.0 compatibility, it ensures future-proof connectivity for advanced GPUs and storage devices. Its robust power design and comprehensive cooling solutions maintain stability under heavy workloads, making it an ideal choice for enthusiasts seeking cutting-edge technology and reliability in demanding applications.

Specifications

Edition: ROG STRIX X870E-E GAMING WIFI
Form Factor: ATX
CPU Socket: AM5
Chipset: AMD X870E
Memory Type: DDR5
Memory Channel: Dual (2)
Memory Type (ECC): ECC/Non-ECC
Memory Type (R/U): UDIMM (Unbuffered)
Max. Memory Capacity: 192GB (4x48GB)
Audio: ROG SupremeFX 7.1 HD Audio
Primary GPU Interface: PCIe 5.0 (x16)
On-Board Graphics Connectors: HDMI 2.1, USB 4.0

Expansion Slots
1 x M.2, 22-42/60/80, PCIe Gen4x4
2 x M.2, 22-42/60/80, PCIe Gen5 x4
1 x M.2, 22-42/60/80/110, PCIe Gen5x4
2 x M.2, 22-80, PCIe Gen4x4
1 x PCIe 5.0 x16
4 x SATA 6GB/s

SATA Support: SATA3 / M.2
Storage Mode Support: RAID 0, RAID 1, RAID 10, RAID 5

Internal I/O
1 x 24-pin (Power)
1 x 4-pin AIO_PUMP Connector
5 x 4-pin CHA_FAN connector
1 x 4-pin CPU Fan Connector
1 x 4-pin CPU OPT Fan Connector
2 x 8-pin (Power)
3 x Addressable Gen 2 Header
1 x FlexKey Button
1 x Front Panel Audio Header
5 x M.2
1 x ReTry Button
4 x SATA III - 6Gb/s
1 x START (Power On) button
1 x Thermal Sensor Header
3 x USB 2.0 Header
2 x USB 3.2 Gen1
1 x USB 3.2 Gen2 Type-C Header

Network Interface Type: 802.11be Wi-Fi 7 LAN, Wired 5 Gigabit LAN (5000)
Network Chip/Modules: 1 x 802.11be WiFi 7, 1 x Realtek (5GbE LAN)

Rear I/O Connectors
1 x 10/100/1000/2500 (LAN)
1 x 100/1000/2500/5000 (LAN)
1 x BIOS Flashback Button
1 x Clear CMOS Button
1 x HDMI 2.1
1 x Line Out
1 x Mic-In
1 x S/PDIF-Out (Optical)
9 x USB 3.2 Gen2 Type-A
1 x USB 3.2 Gen2 Type-C
1 x USB 3.2 Gen2 Type-C /w PD
2 x USB 4.0 Type-C PD/Display
1 x WiFi Module

Cooling: Passive Heatsinks
QPI Speed: N/A
Board Dimensions: 305 x 244 mm
