Asus ROG STRIX B850‑E GAMING WIFI ATX AM5 Motherboard – DDR5, Wi‑Fi 7, PCIe 5.0
Asus ROG STRIX B850‑E GAMING WIFI AM5 DDR5
Build a high‑performance AM5 system with the ASUS ROG STRIX B850‑E GAMING WIFI, a premium ATX motherboard designed for Ryzen 7000 / 8000 / 9000 Series processors. Powered by the AMD B850 chipset, it delivers next‑generation performance with DDR5 up to 8000+ MT/s (O.C), PCIe 5.0 GPU support, five M.2 slots including PCIe 5.0, Wi‑Fi 7, 5Gb LAN, and advanced ROG thermal solutions. ASUS technologies such as Q‑Design, USB4, BIOS FlashBack, Clear CMOS, Aura Sync, and SupremeFX audio ensure easy installation, excellent stability, and long‑term durability — ideal for modern high‑end AM5 gaming and productivity builds.
Specifications
Type: ATX Motherboard
Brand: ASUS
Model: ROG STRIX B850‑E GAMING WIFI
Chipset: AMD B850
CPU Socket: AM5
Supported CPUs: AMD Ryzen 9000 / 8000 / 7000 Series
Memory
RAM Technology: DDR5 (Dual Channel)
RAM Slots: 4 × DIMM
RAM Speed Support: Up to DDR5 8000+ MT/s (O.C)
Max Memory: 192GB
ECC Support: ECC & Non‑ECC UDIMM
Profiles: AMD EXPO & ASUS AEMP
PCIe Slots:
1 × PCIe 5.0 x16 (Q‑Release Slim)
1 × PCIe 4.0 x16 (x4 mode).
Modes vary by CPU generation.
M.2 Slots:
2 × PCIe 5.0 x4
3 × PCIe 4.0 x4
SATA Ports: 4 × SATA 6Gb/s
RAID Support: RAID 0 / 1 / 5 / 10 (RAIDXpert2)
Networking
LAN: Realtek 5Gb Ethernet with ASUS LANGuard
Wireless: Wi‑Fi 7 (2×2)
Bluetooth: 5.4
Audio
Codec: ROG SupremeFX ALC4080
Channels: 7.1‑Channel HD Audio
Features:
Savitech AMP
gold‑plated jacks
Optical S/PDIF out
Video Outputs
(Requires Ryzen CPU with integrated graphics)
1 × HDMI (4K@60Hz)
1 × DisplayPort (8K@30Hz)
1 × USB4 (4K@60Hz)
Special Features
ASUS Q‑Design (M.2 Q‑Latch, PCIe Q‑Release Slim)
ASUS Thermal Solution (M.2 heatsinks)
Aura Sync RGB (Gen 2 headers)
BIOS FlashBack & Clear CMOS
ROG Exclusive Software (Dolby Atmos, ROG CPU‑Z)
Armoury Crate support
UEFI BIOS with advanced features
USB Connectivity Rear I/O
1 × USB4
1 × USB‑C 20Gbps
6 × USB‑A 10Gbps
4 × USB 2.0
HDMI
DisplayPort
5GbE LAN
Audio jacks (3×)
Internal Headers
24‑pin ATX
2 × 8‑pin CPU power
1 × USB‑C 10Gbps header
1 × USB 3.2 Gen1 header
2 × USB 2.0 headers
Front panel audio
TPM header
3 × ARGB Gen2 headers
1 × RGB header
Q‑Flash Plus button
Form Factor: ATX (305 × 244 mm)
Colour: Black
Backplate: Yes
Built‑In I/O Shield: Yes
